Mapping a major QTL responsible for dwarf architecture in Brassica napus using a single-nucleotide polymorphism marker approach

  • Yankun Wang1, 2,
  • Wenjing Chen1, 2,
  • Pu Chu1, 2,
  • Shubei Wan1, 2,
  • Mao Yang1, 2,
  • Mingming Wang1, 2 and
  • Rongzhan Guan1, 2Email author
Contributed equally
BMC Plant BiologyBMC series – open, inclusive and trusted201616:178

https://doi.org/10.1186/s12870-016-0865-6

Received: 3 February 2016

Accepted: 5 August 2016

Published: 18 August 2016

Abstract

Background

Key genes related to plant type traits have played very important roles in the “green revolution” by increasing lodging resistance and elevating the harvest indices of crop cultivars. Although there have been numerous achievements in the development of dwarfism and plant type in Brassica napus breeding, exploring new materials conferring oilseed rape with efficient plant types that provide higher yields is still of significance in breeding, as well as in elucidating the mechanisms underlying plant development. Here, we report a new dwarf architecture with down-curved leaf mutant (Bndwf/dcl1) isolated from an ethyl methanesulphonate (EMS)-mutagenized B. napus line, together with its inheritance and gene mapping, and pleiotropic effects of the mapped locus on plant-type traits.

Results

We constructed a high-density single-nucleotide polymorphism (SNP) map using a backcross population derived from the Bndwf/dcl1 mutant and the canola cultivar ‘zhongshuang11’ (‘ZS11’) and mapped the dwarf architecture with the down-curved leaf dominant locus, BnDWF/DCL1, in a 6.58-cM interval between SNP marker bins M46180 and M49962 on the linkage group (LG) C05 of B. napus. Further mapping with other materials derived from Bndwf/dcl1 narrowed the interval harbouring BnDWF/DCL1 to 175 kb in length and this interval contained 16 annotated genes. Quantitative trait locus (QTL) mappings with the backcross population for plant type traits, including plant height, branching height, main raceme length and average branching interval, indicated that the mapped QTLs for plant type traits were located at the same position as the BnDWF/DCL1 locus.

Conclusions

This study suggests that the BnDWF/DCL1 locus is a major pleiotropic locus/QTL in B. napus, which may reduce plant height, alter plant type traits and change leaf shape, and thus may lead to compact plant architecture. Accordingly, this locus may have substantial breeding potential for increasing planting density.

Keywords

Brassica napus Dwarf architecture with down-curved leaf mutant Single-nucleotide polymorphism Gene mapping

Background

Traits related to plant height or compact plant type are very important due to their role in enhancing lodging resistance or the planting density in crops [14]. Certain key genes related to plant type traits have played very important roles in crop genetic improvement. In wheat, the Rht (Reduced height) genes controlling a key step in the signal transduction pathway of the growth hormone gibberellic acid (GA), have been utilized worldwide, bringing about the “green revolution” in crop production [1]. In rice, a semi-dwarf gene sd1 that regulates a key step in the biosynthesis of GA [57] has proved extremely important in elevating harvest index and lodging resistance in worldwide rice production. However, the mechanism underlying the development of plant type or dwarfism is complex because many loci related to plant hormone biosynthesis and signal transduction [e.g., GA, brassinosteroid (BR) and auxin] and transcription factors, might determine plant height and architecture [815].

Rapeseed is one of the crops prone to lodging, which can lead to yield loss and difficulty in harvesting, and thus scientists have paid considerable attention to dwarfism in B. napus [1619]. The dwarf gene Bzh, which was derived from the cultivar ‘Primor’ through chemical mutagenesis, was first identified and later mapped in 1995 [16, 17]. The dwarf gene Bzh has an additive effect, which may bring about a greater than 30 % reduction in plant height [16, 17]. Using this gene, several dwarf or semi-dwarf rapeseed cultivars, such as ‘Bienvenu-bzh’, ‘2405-bzh’ and ‘Darmor-bzh’ (with formally released genome sequences), have been raised. Muangprom et al. [2022] identified and studied the dwarf gene Brrga1-d on the A06 chromosome of Brassica rapa, which encodes a DELLA protein, and transferred this to B. napus cultivars. Experiments have demonstrated that this gene may reduce plant height and elevate lodging resistance due to an altered GA signaling pathway. Later, the semi-dwarf gene DS-1 in B. napus was mapped to chromosome A06. Molecular experiments have demonstrated that DS-1 encodes a DELLA protein in which a single proline (P) to leucine (L) substitution in the VHYNP motif leads to dwarf mutation, a gain-of-function mutation in GA signaling [18]. In another study, the dwarfism of B. napus banC.dwf, was found to be controlled by one recessive gene that leads to insensitivity to exogenous GA3 [19]. In addition to the aforementioned dwarfism related to GA biosynthesis or signaling, dwarfism related BR signaling or other pathways has also been identified. The phenotype of the B. napus dwarf mutant ‘NDF-1’ was found to be controlled by a major gene possessing a mainly additive effect and a non-significant dominance effect, and a three-base mutation in the pyrimidine box (P-box) of the BnGID1promoter was found to be linked to its dwarf phenotype [23, 24]. Recently, the dominant BnDWF1 locus on chromosome BnA09 has been found to be associated with the B. napus dwarf mutant, Bndwf1 [25].

Although there have been numerous achievements in the exploration of dwarfism and plant type breeding in B. napus, exploring new materials that confer oilseed rape with efficient plant types leading to considerably higher yields is still of significance in breeding, as well as in elucidating the mechanisms underlying plant development. New materials with specific plant type traits, such as compact plant architecture and shorter plant height, are worthy of investigation. The present study describes a dominant dwarf architecture with down-curved leaf mutant (Bndwf/dcl1) isolated from an EMS-mutagenized B. napus line, together with its inheritance, gene mapping and effects on the agronomic traits. Additionally, to map the dominant BnDWF/DCL1 locus and QTLs for plant type-related traits, we constructed a saturated SNP linkage map. Our findings may offer insight into elucidating the molecular mechanism underlying the dominant compact plant type and down-curved leaf phenotype and identification of the key gene controlling the plant height and down-curved leaf trait in B. napus.

Results

Performance of the dwarf down-curved leaf mutant

At the seedling stage, leaves of the Bndwf/dcl1 mutant have a sharply down-curved and crinkled phenotype, with short petioles, which contrasts with the wild-type leaves that are normal with long petioles (Fig. 1a and b). The leaves of the adult Bndwf/dcl1 mutant become slightly down-curved and crinkled before flowering, and are slightly down-curved but not crinkled after flowering. At the mature stage, the Bndwf/dcl1 mutant plant exhibits a compact dwarf plant type, while the wild-type (Fig. 1c) exhibits a tall plant type. Plant height of the Bndwf/dcl1 mutant was only 40–70 cm, which is considerably shorter than that of the wild-type (approximately 1.5 m).
Fig. 1

Morphological charactersof the Bndwf/dcl1 mutant and its wild-type. a Leaf phenotype at the seedling stage of the Bndwf/dcl1 mutant (left) and its wild-type (right). b Phenotype at the seedling stage of the Bndwf/dcl1 mutant (left) and its wild-type (right). c Phenotype at the mature stage of the Bndwf/dcl1 mutant (left) and its wild-type (right)

Inheritance of the dwarf architecture with down-curved leaf trait

The F1 plants of ‘ZS11’ × Bndwf/dcl1 had down-curved leaves and dwarf plant height, indicating that the dwarfism and down-curved leaves are dominant traits. The plants in the BC1 population could be divided into two different groups: dwarf plants with down-curved leaves, and tall plants with normal flat leaves (Fig. 1). The 423 BC1 plants contained 223 dwarf plants with down-curved leaves and 200 normal plants with normal leaves. A chi-squared test indicated that the segregation pattern agreed with the Mendelian segregation ratio of 1:1 (Table 1). In the F2 population, the segregation obeyed the Mendelian segregation ratio of 1:3 (normal plants with normal flat leaves: dwarf plants with down-curved leaves) (Table 1). The reciprocal F2 population (RF2) was verified to have the same inheritance segregation mode as the F2 population (Table 1). Thus, we infer that the dwarf architecture with down-curved leaf trait is controlled by a single dominant gene.
Table 1

Inheritance of the dwarf architecture with down-curved leaf trait of Bndwf/dcl1

Population

No. of normal plants with normal leaves

No. of dwarf plants with down-curved leaves

Expected segregation

χ 2

p value

BC1

200

223

1 : 1

1.14

0.29

F2

126

319

1 : 3

2.43

0.12

RF2

97

247

1 : 3

1.71

0.19

Several plant type-related traits were investigated in the backcross population. It was found that the plants with down-curved leaves were consistently dwarf and compact in plant type. For plants with down-curved leaves, measurements for plant height, branching height, main raceme length and average branching interval, were all significantly smaller than those of the plants with normal leaves (Table 2). The plant height was on average reduced by approximately 60 % compared with the normal plants. Plant height was significantly correlated with branching height, main raceme length and average branching interval, with correlation coefficients r = 0.868**, 0.945** and 0.736** respectively (** denotes significant at the 0.01 level, see Additional file 1). These results clearly indicate that the down-curved leaf trait is accompanied by compact plant type architecture by reduced branching height, main raceme length and branching interval. However, the compact type of plant architecture does not necessarily indicate reduction in the number of the primary branches (Table 2). Additionally, in the BC1 population, the 1000-seed weight and yield per plant of dwarf plants with down-curved leaves were both significantly less than those of the normal plants with normal leaves (Table 2).
Table 2

Agronomic performance of the Brassica napus ‘ZS11’ × (‘ZS11’ × Bndwf/dcl1) BC1 population

Trait

‘ZS11’

Bndwf/dcl1

F1

BC1 population

Normal plants with normal leaves

dwarf plants with down-curved leaves

p value

Plant height

143.5 ± 7.0

49.3 ± 8.7

56.2 ± 2.6

122.5 ± 13.0

48.2 ± 8.0b

1.7E-237

Branching height

29.2 ± 3.5

9.9 ± 3.8

11.9 ± 3.8

34.0 ± 7.6

10.2 ± 3.3b

2.2E-155

Main raceme length

72.3 ± 6.6

24.4 ± 4.2

29.6 ± 5.1

57.9 ± 9.3

25.3 ± 6.1b

1.6E-156

Average branching interval

6.6 ± 1.0

3.4 ± 2.1

3.5 ± 1.4

7.1 ± 2.0

3.2 ± 1.6b

5.5E-76

No. of primary branches

7.4 ± 1.2

5.7 ± 1.1

5.3 ± 0.9

5.4 ± 1.4

5.2 ± 1.4

0.22

Yield per planta

24.3 ± 4.1

14.0 ± 2.9

14.9 ± 3.1

18.5 ± 11.2

14.7 ± 8.4b

0.00011

1000-seed weighta

4.570 ± 0.304

3.426 ± 0.702

4.221 ± 0.394

4.364 ± 0.521

3.924 ± 0.660b

3.28E-13

a Indicates that the trait with this sign was investigated in 20 individuals randomly sampled from dwarf and tall subpopulations, respectively

b Indicates significant differences between dwarf and tall plants at the 0.01 level by t-test. Data are presented as mean ± standard deviation (SD)

Construction of a high density SNP map

With the BC1 population derived from ‘ZS11’ × (‘ZS11’ × Bndwf/dcl1), we genotyped 109 plants. Although the Brassica 60 K SNP BeadChip has 52,157 SNP markers, after deleting invalid markers, only 14,682 polymorphic markers were used to construct the linkage map. Nineteen LGs obtained by JoinMap 4 software contained 818 bins representing 7489 markers (for detailed data see Additional file 2). The total length of the map was 1583.05 cM, the longest LG was C03 at 134.54 cM and the shortest LG was C09 at only 22.91 cM (Table 3). The mean interval between adjacent markers was 1.98 cM. This high-density map may be used for mapping the BnDWF/DCL1 locus and the loci of other agronomic traits.
Table 3

Statistics of the LGs constructed from the BC1 population of Brassica napus

LG

Bin

Marker

Length (cM)

Mean interval (cM)

Max interval (cM)

Min interval (cM)

A01

51

403

75.67

1.51

9.67

0.11

A02

34

298

110.88

3.36

18.44

0.66

A03

66

439

133.96

2.06

16.06

0.27

A04

46

591

92.24

2.05

19.74

0.17

A05

66

630

95.63

1.47

12.14

0.10

A06

62

342

122.12

2.00

14.69

0.19

A07

48

323

71.47

1.52

7.85

0.17

A08

34

416

41.08

1.24

4.34

0.08

A09

66

599

119.57

1.84

11.19

0.21

A10

24

129

47.24

2.05

12.79

0.24

C01

33

447

86.53

2.70

19.09

0.23

C02

60

622

71.36

1.21

10.68

0.14

C03

61

628

134.54

2.24

18.00

0.38

C04

33

489

58.66

1.83

6.85

0.20

C05

26

187

64.75

2.59

13.37

0.44

C06

27

289

57.19

2.20

10.25

0.26

C07

34

242

65.09

1.97

10.50

0.36

C08

36

303

112.16

3.20

15.38

0.24

C09

11

113

22.91

2.29

9.48

0.68

Total

818

7489

1583.05



Mapping of BnDWF/DCL1

After building the saturated SNP genetic map, the BnDWF/DCL1 locus was mapped onto LG C05, positioned in an interval of 6.58 cM between SNP bins M46180 and M49962 (Fig. 2a). A search of the B. napus genome database had shown that SNP probe sequences of the two flanking markers matched completely with their physical position on chromosome C05 in B. napus cv. ‘Darmor-bzh. On the basis of the genome sequence of B. napus cv. ‘Darmor-bzh’, the BnDWF/DCL1 locus is inferred to reside within a region of 16.354 Mb on C05 of B. napus cv. ‘Darmor-bzh’. LG C05 was 64.75 cM long and contained 26 bins representing 187 SNP markers, indicating that the chromosome C05 of B. napus had enriched SNP markers in our population. Unfortunately, the target interval harbouring the BnDWF/DCL1 locus did not have polymorphic SNP markers, leading to a failure in identifying the nearest recombination site by using this population.
Fig. 2

Mapping of BnDWF/DCL1 with SNP and SSR markers using BC1 and F5 populations. a The BnDWF/DCL1 locus was mapped by SNP marker at position of 61.00 cM of LG C05 in the BC1 population, which was in a 6.58-cM region between M46180 and M49962. b SNP screening of 29 F5 individuals narrowed the BnDWF/DCL1 locus to the interval between M41893 and M24830 (1.08 Mb, the blue segment) of chromosome C05 in B. napus cv. ‘Darmor-bzh’, and this was co-segregated with M24343 and M24345. c SSR marker screening resulted in further mapping of the BnDWF/DCL1 locus to the interval between SSR markers BnC05E106 and BnC05E209 (175 kb)

QTL mapping related to plant type

In addition to mapping of BnDWF/DCL1, we also mapped QTLs for agronomic traits in the BC1 population. As a result, we identified a single major QTL for plant height on LG C05, termed qPHC05, which explained 79.5 % of the phenotypic variation in plant height (Table 4). It apparently mapped at the same position as the BnDWF/DCL1 locus, had a large LOD score of 35.0 (see Additional file 3), and had a high genetic effect (-62.30 cm). This probably indicates the BnDWF/DCL1 locus (QTL) not only causes changes in leaf shape, but also reduces plant height in plants carrying the dominant BnDWF/DCL1 locus. Furthermore, we identified a QTL for branching height (qBHC05), a QTL for main raceme length (qMRLC05), and a QTL for average branching interval (qABIC05). These QTLs of traits related to plant type were at approximately the same position as BnDWF/DCL1. They consistently had high LOD values (see Additional file 3), obvious genetic effects and high phenotypic variation explained (PVE) percentages (Table 4). Thus, we conclude that the BnDWF/DCL1 locus (QTL) probably has a pleiotropic effect on plant type. In other words, the dominant locus BnDWF/DCL1 causes elemental shrinkages in the plant architecture, leading to pleiotropic effects on different parts of plants. It is noted that the position of this dwarf locus together with its related traits are all different from the reported dwarf QTLs in B. napus.
Table 4

QTLs identified for agronomic traits in the BC1 population derived from parents ‘ZS11’ and Bndwf/dcl1

Trait

QTL

LG

Position

Marker interval

LOD

Effect

PVE (%)

Plant height

qPHC05

C05

61.1

M46180-M49962

35.0

−62.30

79.5

Branching height

qBHC05

C05

61.0

M46180-M49962

26.8

−20.28

71.2

Main raceme length

qMRLC05

C05

61.0

M46180-M49962

22.3

−27.37

65.2

Average branching interval

qABIC05

C05

61.5

M46180-M49962

10.9

−3.82

41.4

Further mapping of the BnDWF/DCL1 locus

The above-mentioned mapping interval for BnDWF/DCL1 was too long to be of value for further studies due to the lack of polymorphic SNP markers in the mapping interval. To solve this problem, we investigated 29 F5 individuals derived from the cross between the European rapeseed cultivar ‘Tapidor’ and Bndwf/dcl1. Genotyping the 29 F5 individuals using the Brassica 60 K SNP BeadChip Array revealed that the BnDWF/DCL1 locus co-segregated with SNP markers M24343 and M24345, and seven recombinants were found among the 29 F5 individuals. Of these, six recombinants with down-curved leaves were observed be recombined between M24343 and M41893, and one line with down-curved leaves was observed to show recombination between M24345 and M24380. Information from markers M41893, M24343, M24345 and M24380 helped narrow the mapping interval to a 1.08-Mb region between M41893 and M24380, and there were no other polymorphic SNP markers in this region (Fig. 2b).

On the basis of this revised mapping interval and its corresponding genome sequence, 155 simple sequence repeat (SSR) markers were designed to clarify the recombination site by polymerase chain reaction (PCR). Nine of the designed SSR markers were found to be polymorphic: BnC05E054, BnC05E059, BnC05E060, BnC05E062, BnC05E087, BnC05E106, BnC05E209, BnC05E474 and BnC05E485 (see Additional file 4). By genotyping the seven F5 recombinant individuals using these nine polymorphic markers, fortunately, we found that the BnDWF/DCL1 locus can be mapped to the interval between BnC05E106 and BnC05E209, based on recombination site analysis with SSR markers. The relative orders and positions of all the polymorphic SNP and SSR markers on LG C05 and chromosome C05 of B. napus cv ‘Darmor-bzh’ are unanimous (Fig. 2). Accordingly, the mapping interval between BnC05E106 and BnC05E209 was identified to be 175 kb in length on basis of their positions on the C05 chromosome of B. napus cv. ‘Darmor-bzh’ (Fig. 2c). No polymorphic SSR marker other than the nine SSR markers can be found in this small region, which was progressively determined by our careful investigation.

To validate these results, the remaining plants of the F5 family populations were genotyped using the SSR markers. PCR detection in the segregating or homologous F5 family populations produced results that were consistent with those of previous experiments, including phenotype observations and marker genotyping. Thus we may conclude that the BnDWF/DCL1 locus is located in a 175-kb interval between BnC05E106 and BnC05E209 on chromosome C05 of B. napus cv. ‘Darmor-bzh’.

Additionally, our analysis for the fine mapping of the BnDWF/DCL1 locus was based on a formally released genome sequence database of B. napus cv. ‘Darmor-bzh’. Nevertheless, segments homologous to that harbouring the BnDWF/DCL1 locus cannot be found in the genome database of B. napus cv. ‘ZS11’. However, in this database, we did find two highly homologous matches to the mapping segment, which were a segment of 86.78 kb in length on chromosome C04 (from 25534021 to 25620800), and a segment of 91.6 kb in length on chromosome C05 (from 29448801 to 29540400) (Additional file 5). Theoretically, it is of very small probability to depart two segments homologous to an entire segment by an evolutionary event at recent time. Thus, it may be inferred that the disparity between two public sources of genome information regarding this region is due to an error that occurred in assembly of the genomes of the allotetraploid species B. napus. However, strong systematic evidence from the aforementioned SNP and SSR marker experiments, such as recombination percentage and marker cosegregation information, consistently support our contention that the results based on the genome database of B. napus cv. ‘Darmor-bzh’ are reliable for this work. Analysis of the annotation information of the 175-kb mapping interval revealed that the chromosomal segments harbouring the BnDWF/DCL1 locus in B. napus cv. ‘Darmor-bzh’ contain 16 annotated genes found in public databases (http://brassicadb.org/brad/downloadOverview.php) (Additional file 6).

Discussion

Although studies of plant type regulation in plant species have been intensified, the new applicable gene is rare. Mining the key genes related to plant type is still of significance in many crops. Compact plant type may be used to increase planting density in B. napus, with the aim of elevating yield per unit area. A compact plant type together with the down-curved leaves phenotype was observed in a population derived from the Bndwf/dcl1 mutant. The BnDWF/DCL1 locus position and its related traits are all different from that of the reported dwarf QTLs in B. napus [1625]. The BnDWF/DCL1 locus has a more obvious effect on reducing plant height than these reported rapeseed dwarf loci and confers plants with compact architecture, thus, this will certainly be of value in breeding a variety with compact plant type because the moderate penalty of the dwarfism may possibly be compensated or overcome by increased planting density. However, in the future, the breeding potential of the Bndwf/dcl1 mutant will need to be explored with attention paid to breeding strategies, although we still consider that it will be of significance in oilseed rape breeding.

Use of SNP markers has been beneficial to plant genotyping efforts because of the numerous distinct markers and high genome coverage [2628]. In B. napus, the Brassica 60 K SNP BeadChip Array has recently helped advance rapeseed research efforts, and enabled the efficient construction of several high-quality saturated linkage maps over a short period [25, 2932]. By using this SNP chip in the present study, we constructed a saturated B. napus map, with 818 bins containing 7489 markers and a total length of 1583.05 cM. The BnDWF/DCL1 locus was primarily mapped to a 6.58-cM interval between M46180 and M49962 of B. napus chromosome C05. The SNP marker distance of 6.58 cM corresponds to the physical map length (16.354-Mb). This indicated that the mapping interval may contain a centromere since the physical distance is not consistent with the observed phenomena that 1 cM is on average equivalent to a genomic sequence length of 0.4–0.5 Mb in B. napus.

Although our investigations were initially limited by the lack of polymorphic molecular markers in the target mapping interval, we fortunately had alternative accessions that were derived from the cross between ‘Tapidor’ and Bndwf/dcl1, which have undergone recombination in the selfing and breeding process. The enriched materials prepared in this research helped us to progressively approach the target genes.

Compared with many other traditional mapping techniques, our mapping procedure included the additional step of homologous segment analysis. Indeed, this analysis is probably a necessary step in the mapping. Newly constructed public Brassica genome databases cannot entirely exclude the possibly of certain genome assembly errors, which may lead to the inaccurate mapping intervals. Analysis integrated with marker experimental information may help to perfect the mapping results, as this will clarify which sequences are more reliable in cases where there is disparity between two or more homologous genome sequence segments.

Various mechanisms underlying plant dwarfism have been reported. Genes participating in biosynthesis and signal transduction of plant hormones, such as GA, BR and auxin, have been related to dwarf plant architecture. Dwarfism may also be affected by homeotic genes and genes related to the cell wall, polyamine biosynthesis and transcription factors. The present study has revealed the genes within a designated mapping interval, which contains genes with functions similar to those reported to be associated with plant dwarfism. However, further studies are required to identify the gene responsible for the dwarf architecture with down-curved leaf mutant trait in B. napus.

Conclusions

The BnDWF/DCL1 locus was demonstrated to be associated with the dwarf architecture with down-curved leaf trait in B. napus. Construction of a high-density SNP map enabled us to position the BnDWF/DCL1 locus in a 6.58-cM interval on LG C05 of B. napus. Further mapping with other materials derived from Bndwf/dcl1 enabled us to narrow the interval for BnDWF/DCL1 to 175-kb. QTL mapping indicated that BnDWF/DCL1 to be a major dominant locus that has pleiotropic effects on leaf type and changes in plant type traits. Our findings have revealed a key locus with plant type breeding potential, and may offer insights into elucidating the molecular mechanism underlying the dominant plant type in B. napus.

Methods

Plant materials

The B. napus dwarf architecture with down-curved leaf mutant, Bndwf/dcl1, was originally isolated from an EMS-mutagenized B. napus pure line, NJ7982, at Nanjing Agricultural University, China. The dwarf architecture with down-curved leaf mutant was crossed with canola variety ‘ZS11’, and then backcrossed with ‘ZS11’ to produce the BC1 generation. We phenotyped the BC1 population plants at the seedling and mature stages. Fourteen normal plant DNA samples, 95 down-curved leaf plant DNA samples, and DNA from the recessive recurrent parent, ‘ZS11’, were then used for SNP genotyping. Two reciprocal F2 populations derived from the same cross were also used for genetic analysis.

One homologous selfing F5 family (contains 153 dwarf plants with down-curved leaves) and three segregating selfing F5 families (contain 14, 12 and 13 dwarf plants with down-curved leaves and 14, 8 and 5 normal plants with normal leaves, respectively) derived from the cross of “Tapidor × Bndwf/dcl1” were used to further map the dwarf architecture with down-curved leaf locus. Some of plants with dwarf architecture in the segregating families died because they were shadowed by taller plants, thus the data of the segregating families were not used for chi-square test. Twenty-nine individuals (23 dwarf plants with down-curved leaves and 6 normal plants with normal leaves) from the four F5 families were used for SNP marker genotyping with aim of further mapping the BnDWF/DCL1 locus. All plants of these populations were used to identify recombination sites resulting from the breeding process, using SSR markers.

All materials were grown at the same density in fields of the Jiangpu Experimental Station at the Nanjing Agricultural University. Plants were sown uniformly in rows of 2.5 m length with 15 individuals in each row and 0.4 m spacing between rows. The BC1 and two reciprocal F2 populations were grown in 2012. The F5 lines were grown in 2014.

Agronomic traits observation

In the BC1 population, agronomic traits, including plant height, branching height, main raceme length, number of first branches and average branching interval, were investigated in all the individuals, and 20 individuals randomly sampled from dwarf and tall subpopulations, respectively, were used to investigate the yield per plant and 1000-seed weight. Every eight individuals were randomly selected from the parents and F1 of the BC1 population to examine all the agronomic traits.

The plant height (PH) was measured from the ground to the top of the individual, the branching height (BH) was measured from the ground to the first node, and the main raceme length (MRL) was measured from the last branch base to the top of the plant. The average branching interval (ABI) was calculated using the following formula:
$$ ABI=\left(PH-BH-MRL\right)/\left( number\; of\; first\; branches-1\right). $$

Construction of a SNP genetic map

Total DNA was extracted from fresh leaves using a modified cetyl trimethylammonium bromide (CTAB) method [33]. The DNA samples were diluted to 200 ng uL−1 and then genotyped using the Brassica 60 K SNP BeadChip Array. There are a total of 52,157 SNP markers in the Brassica 60 K SNP BeadChip Array, which is sufficient to genotype our DNA samples. DNA sample preparation, hybridization to the BeadChip and imaging of the arrays were performed by the Beijing Emei Tongde Development Co. Ltd (Beijing, China). Allele calling for each locus was performed using GenomeStudio genotyping software v2011.1 (Illumina, Inc.). Cluster definitions were based on genotype data from rapeseed individuals. The SNP markers were named using M plus index numbers assigned by GenomeStudio, which are presented in the text and their original names are listed in Additional file 2.

The polymorphic SNP markers were first sorted into different bins. The first marker within each bin was selected as the representative of the bin and was used to construct the linkage map with JoinMap 4 software [34]. The SNP markers were first grouped to different LGs at a recombination frequency of 0.22 using the “Population” function. The marker order and distances in each LG were calculated using the Regression mapping algorithm. The Kosambi function was used for calculating the cM map distances with a logarithm of odds (LOD) threshold of 1.0 and recombination frequency of 0.4.

Mapping of the BnDWF/DCL1 locus and QTLs for agronomic traits

A genetic map was constructed from the backcross population using the Brassica 60 K SNP BeadChip Array data. Detection of the BnDWF/DCL1 locus and QTLs for plant type-related agronomic traits was performed for the BC1 population using the inclusive composite interval mapping (ICIM) method [35]. The LOD threshold for QTL detection was determined by permutation test analyses (1000 permutations, 5 % overall error level).

Further mapping of the BnDWF/DCL1 locus

On the basis of the constructed SNP map, the physical regions containing the BnDWF/DCL1 locus were identified by aligning SNP probe sequences with the genomes of B. napus cv. ‘Darmor-bzh’ using BLASTN (http://blast.ncbi.nlm.nih.gov/). The locus of the B. napus cv. ‘Darmor-bzh’ genome, where the genome sequence has 100 % identity with the SNP probe sequence, is the perfect position of the corresponding SNP marker on it. The Brassica 60 K SNP BeadChip Array was used to genotype the 29 F5 individuals derived from the cross between ‘Tapidor’ and Bndwf/dcl1.

Following gene mapping by these methods, the interval sequences of approximately 1 Mb covering the significant SNP markers related to the mutant locus were downloaded from http://www.genoscope.cns.fr/brassicanapus/data/ for bioinformatics analysis. On the basis of the sequences of B. napus cv. ‘Darmor-bzh’ physical region containing the BnDWF/DCL1 locus, 637 SSR loci were identified using SSRHunter 1.3 software [36] with a 6-bp motif maximum and three-repeat minimum. Of these, 155 SSR loci with a 150-bp sequence on both sides were selected to design primers using the Primer Premier 5.0 software [37] (see Additional file 7). The PCR conditions were as follows: denaturation at 95 °C for 10 min, followed by 35 cycles of 95 °C for 30 s, annealing for 40 s (the annealing temperature of each SSR marker is listed in Additional file 7), and 72 °C for 40 s, and a final extension step at 72 °C for 10 min.

The nine polymorphic markers identified from these 155 designed SSR markers were used for genotyping the F5 lines derived from a crosses between ‘Tapidor’ and the Bndwf/dcl1 mutant, to determine the recombination site in the breeding materials with the aim of narrowing the mapping interval.

Analysis of genes in the mapping interval of the BnDWF/DCL1 locus

Whole genome sequences of B. napus cv. ‘Darmor-bzh’ were downloaded from public databases (http://www.genoscope.cns.fr/brassicanapus/) [38]. On the basis of the positions of SSR and SNP markers on the genome, the corresponding physical region of mapping interval could be obtained. A bioinformatics analysis of annotated genes in the mapping region was then completed.

Abbreviations

‘ZS11’:

‘Zhongshuang11’

Bndwf/dcl1

Dwarf architecture with down-curved leaf mutant

BR:

Brassinosteroid

CTAB:

Cetyl trimethylammonium bromide

EMS:

Ethyl methanesulfonate

GA:

Gibberellic acid

ICIM:

Inclusive composite interval mapping

LG:

Linkage groups

LOD:

Logarithm of odds

PCR:

Polymerase chain reaction

QTL:

Quantitative trait locus

SNP:

Single-nucleotide polymorphism

SSR:

Simple sequence repeat

Declarations

Acknowledgments

We thank Prof. Shengyi Liu and Prof. Wei Hua in Oil Crops Research Institute of the Chinese Academy of Agricultural Sciences for their guidance and support in SNP markers analysis.

Funding

This research was supported financially by the National Natural Science Foundation of China (31301352 and 31270386), the Fundamental Research Funds for the Central Universities of China (KYZ201202-7 and KJQN201423), the Jiangsu Agricultural Science and Technology Innovation Fund (JASTIF) (CX (14)2003), and the Priority Academic Program Development of Jiangsu Higher Education Institutions (PAPD) of China.

Availability of data and materials

All data generated or analyzed during this study are included in this published article and its supplementary information files.

Author’s contributions

YW conducted the map construction and locus mapping, drafted the MS; WC, SW, MY and MW co-finished the experiments; PC modified the MS; RG conceived and supervised the research and polished the MS. All authors have read and approved the manuscript.

Competing interests

The authors declared that they have no competing interests.

Consent for publication

Not applicable.

Ethics approval and consent to participate

This study required no ethics approval.

Open AccessThis article is distributed under the terms of the Creative Commons Attribution 4.0 International License (http://creativecommons.org/licenses/by/4.0/), which permits unrestricted use, distribution, and reproduction in any medium, provided you give appropriate credit to the original author(s) and the source, provide a link to the Creative Commons license, and indicate if changes were made. The Creative Commons Public Domain Dedication waiver (http://creativecommons.org/publicdomain/zero/1.0/) applies to the data made available in this article, unless otherwise stated.

Authors’ Affiliations

(1)
State Key Laboratory of Crop Genetics and Germplasm Enhancement, Nanjing Agricultural University
(2)
Jiangsu Collaborative Innovation Center for Modern Crop Production
